| Image Sensor | 1/3” Progressive Scan CMOS |
| Pan/Tilt/Rotation Range | Pan: 0˚ ~ 360˚, Tilt: 0˚ ~ 85˚, Rotation: 0˚ ~ 360˚ |
| Lens Type | Fixed focal |
| Iris | Fixed Iris |
| Focal length | 2.8 mm |
| F Number | F 2.0 |
| Angle of View | H: 93.2°, V: 50.2° |
| Streaming Capability | 2 streams |
| Stream/Frame Rate | Main Stream: 2560×1920, 2560×1440, 2304×1296, 1920×1080, 1280×720, 704×576 @ 20fps Sub Stream: 640×360 @ 20fps |
| Bit Rate | CBR/VBR, Main Stream: 512kbps ~ 6144kbps, Sub Stream: 128kbps ~ 1536kbps |
| Image Adjustment | Brightness/Sharpness/Contrast/Saturation |
| Maximum resolution | 5MP, 2560(H)×1920(V) |
| White balance | Auto/Manual |
| Support Features | Mirror, Motion Detection, Privacy Masking, Human Detection, Reset Button, Built-in Microphone |
| 3D Digital Noise Reduction | 2D/3D NR |
| Image Enhancement | DWDR/HLC/BLC/Defog |
| Protocols | IPv4, RTSP/RTP/RTCP, TCP/UDP,DHCP, DNS, DDNS, UPNP, ICMP, IGMP, NTP, SMTP, 802.1x, SNMP, HTTP/HTTPS, PPPOE |
| Interoperability | ONVIF, SDK |
| Max. User Access | 4 Users |
| Web Viewer | <IE11, Chrome, Firefox, Microsoft Edge |
| Management Software | InView Pro |
| Smart Function | Intrusion and Line crossing detection based on human detection |
| Electronic shutter | Auto/Manual, 1/5 ~ 1/20,000s |
| Ethernet | 1 Ethernet (10/100 Base-T) RJ-45 Connector |
| Operating and Storage Temperature | Micro SD slot, up to 256GB |
| Power Supply | DC12V/POE (IEEE 802.3af) |
| Power Consumption | Max 5W |
| Operating temperature | -25°C ~ 55°C (-13°F ~ 131°F ) |
| Operating humidity | Less than 90% RH |
| Ingress Protection | IP66 |
| Certifications | CE/FCC |
| Casing | Metal |
| Dimensions | Φ111 × 95mm |
| Minimum Ilumination | Color: 0.1 Lux @ (F1.6,AGC ON) ,B/W: 0 Lux @ (IR LED ON) |
| Net Weight | 0.35 kg (0.77 lb) |
| Compression | H.264/ H.265/ H.265+ (Smart Encode) |
| Signal to Noise Ratio S/N | 55 dB |
| Day-Night Mode | Auto/ Day/ Night/ Timing |
| Wide Dynamic Range | DWDR |
| IR Range | IR distance up to 30m (98.4 ft) White light distance up to 30m (98.4 ft) |
| IR On/Off Control | Auto/Manual |
